GCS Tactical Handheld Controller

SMALL AND ROBUST GROUND CONTROLLER WITH HIGHLY INTUITIVE CYBERSECURE INTERFACE TO CONTROL AND MONITOR MULTIPLE UNMANNED VEHICLES AND POLE CAMERA HEADS INCLUDING OPERATION OF THEIR PLUG-IN PAYLOADS AND SENSORS

Ruggedized and very lightweight, designed to fit operator’s bodyworn equipment, the GCS has an intuitive control interface delivering the best viewing experience for any pilot in any lighting environment.

It is designed as the ideal tactical controller, providing aerial and/or terrestrial device control, whilst collecting mission critical intel.

Whilst avoiding communication via public networks, the GCS uses a strong encryption algorithm to secure data related to control of unmanned vehicles and payload activation; making it virtually un-hackable.

Up-to 4x vehicles/cams

Simultaneous control of up to 4 vectors, giving a single operator multiple tools with which to collect intel

Ergonomic

With no protruding parts, the GCS fits into any operator’s pocket or on his chest using its custom-made cover

Indoor RF Efficency

The GCS embeds top-in-class RF technology that offers the best range for interior and out-of-sight operations whatever the obstacles

No Public Networks

Our purpose-built flight controller does not require internet service, GPS, phone or tablet for deployment

#2 SPECS

Autonomy 200 min.
Weight battery included A 640 gr 1,41 lbs
Ops Temperature 20°C to 50°C 4°F to 122°F
Power Supply Li-lon 6300 mAh Embedded Battery 3.7V

Video Reception

99 db dual ISM receivers 5.8 Ghz
Embedded 9 dbi ceramic array antenna
FPGA scrambled

Command & Control

868-915 UHF
AES256 encrypted

Connector

USB-C main connector
Audio out jack 3.5 mm
Audio-viden out/in jack 3.5 mm

#3 FEATURES

Robust against any communication delay and offering progressive signal degradation, our GCS provides the operator with steady and reliable AES 256 encrypted control of the unmanned vehicles
Deployable antennas, integrated joysticks, all aspects completely flush with outer structure
Diversified analog audio/video receptors, running a 8 bit FPGA scrambling while avoiding any lag or frozen pictures
No cellular network, GPS, applications or smartphones required
Audio/video RCA output
Wireless observer mode for team leader
Multi GCS cooperative mode (wired or wireless)
SD port for software revision and upgrades

#4 ADD-ONS

Padded protective GCS cover to be clamped directly to armour systems via MOLLE/PALS
Wired Trigger Remote to
delegate payload activation to a second operator
